Video Input:

• 32CH Standard BNC + 8CH IP

Video Output:

• HDMI – FHD
• VGA
• CVBS

Recording:

• • HD Analog: 3K/5MP Lite: Up to 10FPS Per Channel /

4MP Lite / 2MP: Up to 12/15FPS Per Channel / 2MP Lite / 1MP: Up to 25/30FPS Per Channel

• CVBS: 960H: Up to 25/30FPS Per Channel
• IP: 5MP and lower: 25/30FPS Per Channel

Playback:

• Local: 16Ch Simultaneously
• Remote: 8Ch Simultaneously

Audio:

• Input: 16C + IPC Inputs
• Output: 1CH + IPC Outputs

Alarm:

• Input: 4+IPC
• Output: 1+IPC

Storage:

• 4 x SATA (Up to 10TB each)
• 1 x E-SATA (Up to 10TB each)

Network:

• 1 x RJ-45: 10/100/1000Mbps

PTZ Support:

• RS-485 / CoC / IP over Network

Power Supply:

• DC12V/4A

Analytics:

AI by IPC:

• DDA1 Analytics Supported by the camera

AI By DVR:

• AI Object detection, Line Crossing/Sterile Area (Up to 1 channel, at the expense of 4 SMD channels)

Remarks:

• The following features are based on firmware v1.4.2.76998_RD250317 and are subject to firmware version changes.
